Professional gray acrylic foam architectural tape with 0.75 inch width and 36 yard length. Provides permanent bonding, water-resistant seal, and smooth invisible fastening for building cladding and panel attachment. UL GREENGUARD certified for sustainable construction.
The 3M™ VHB™ Architectural Panel Tape G16F is a premium gray, 0.062 inch (1.6 mm) multi-purpose acrylic adhesive foam tape with conformable core and polyethylene film liner. Specifically engineered for architectural applications, this professional-grade bonding solution provides fast and easy-to-use permanent bonding with high strength and long-term durability. The tape measures 0.75 inches wide by 36 yards long and comes in a case of 12 rolls, making it ideal for large-scale architectural projects.
This innovative foam tape features a durable acrylic adhesive with viscoelastic properties that delivers extraordinarily strong bonding to a broad range of substrates including aluminum, stainless steel, galvanized steel, composites, plastics, acrylic, polycarbonate, ABS, and painted or sealed wood and concrete. The virtually invisible fastening method keeps surfaces smooth while creating a permanent seal against water, moisture, and environmental elements. It provides excellent shear strength, conformability, surface adhesion, and temperature resistance, with maximum operating temperature of 149°C (300°F).
Designed as an alternative to structural silicone and spacer tapes/gaskets, the 3M VHB Architectural Panel Tape G16F is commonly used for building cladding, exterior architectural panels for curtain walls, and interior panel and trim attachment. The pressure-sensitive adhesive bonds on contact to provide immediate handling strength, allowing the use of thinner, lighter weight, and dissimilar materials. This restricted-use industrial product is UL GREENGUARD and UL GREENGUARD Gold Certified, contributing to LEED credits for sustainable building practices.
Key Features
- Fast and easy-to-use permanent bonding method with high strength and long-term durability
- Virtually invisible fastening keeps surfaces smooth and aesthetically pleasing
- Creates permanent seal against water, moisture, and environmental elements
- Pressure-sensitive adhesive bonds on contact providing immediate handling strength
- Conforms to broad range of substrates including metals, glass, plastics, and composites
- Excellent shear strength, conformability, surface adhesion, and temperature resistance
- UL GREENGUARD and UL GREENGUARD Gold Certified for sustainable building practices
- Prevents bi-metallic corrosion when joining dissimilar materials
- Allows use of thinner, lighter weight materials in construction
- Alternative to structural silicone and mechanical fasteners
Technical Specifications
| Specification |
Value |
| Product Type | Architectural Panel Tape - Foam Adhesive |
| Brand | 3M VHB |
| Model Number | G16F |
| Part Number | G16F |
| UPC Code | 00051111925331 |
| 3M ID | 7000124779 |
| Overall Width (Imperial) | 0.75 inches |
| Overall Width (Metric) | 19.05 mm |
| Overall Length (Imperial) | 36 yards |
| Overall Length (Metric) | 32.92 meters |
| Tape Thickness | 0.062 inches (1.6 mm) |
| Core Size | 3 inches |
| Adhesive Type | Acrylic |
| Foam Type | Conformable Multi-purpose |
| Liner Material | Polyethylene Film |
| Product Color | Gray |
| Maximum Operating Temperature (Fahrenheit) | 300°F |
| Maximum Operating Temperature (Celsius) | 149°C |
| Units per Case | 12 rolls |
| Smallest Saleable Unit | Roll |
| Industries | Construction, Transportation, Architectural |
| Applications | Architectural panels, cladding, decorative metal, panels to frame, stiffener attachment |
| Recommended Uses | Architectural panels for curtain walls, exterior building cladding, interior panel and trim attachment |
| Compatible Substrates | Aluminum, stainless steel, galvanized steel, composites, plastics, acrylic, polycarbonate, ABS, painted or sealed wood and concrete |
| Certifications | UL GREENGUARD and UL GREENGUARD Gold Certified |
| Bonding Method | Pressure-sensitive adhesive - bonds on contact |
| Moisture Resistance | Creates permanent seal against water and moisture |
| Use Type | Industrial/Occupational Use Only - Not for Consumer Sale |
| Storage Conditions | Store in cool, dry conditions |
| Handling Strength | Immediate handling strength upon application |
Order 3M VHB Architectural Panel Tape G16F Gray 0.75 inch at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
