Premium gray architectural foam tape with 45 mil thickness, providing permanent bonding for building cladding and curtain walls with UL GREENGUARD certification
The 3M™ VHB™ Architectural Panel Tape G11F is a premium gray, 0.045 inch (1.1 mm) multi-purpose acrylic foam adhesive tape designed specifically for architectural and construction applications. This innovative bonding solution features a conformable foam core with a polyethylene film liner, delivering exceptional strength and long-term durability for building cladding, curtain walls, and interior panel attachments. The tape combines viscoelastic properties that absorb shock and flexing, providing superior reliability against wind, vibration, and thermal expansion/contraction cycles.
This architectural-grade tape provides a fast and easy-to-use permanent bonding method that eliminates the need for structural silicone, spacer tapes, and gaskets. It creates an invisible fastening solution that keeps surfaces smooth and aesthetically pleasing while offering immediate handling strength upon contact. The pressure-sensitive acrylic adhesive bonds to a broad range of substrates including aluminum, stainless steel, galvanized steel, composites, plastics, acrylic, polycarbonate, ABS, and painted or sealed wood and concrete surfaces.
UL GREENGUARD and UL GREENGUARD Gold Certified, the G11F tape contributes to LEED credit achievement and sustainable building practices. With over 30 years of proven reliability in iconic buildings worldwide, this tape offers exceptional shear strength, conformability, surface adhesion, and temperature resistance. It withstands extreme conditions from Dubai's heat to Canada's cold, making it an ideal alternative to mechanical fasteners like screws, rivets, and welds for permanent architectural applications.
Key Features
- Fast and easy-to-use permanent bonding method with high strength and long-term durability
- Virtually invisible fastening keeps surfaces smooth and aesthetically pleasing
- Viscoelastic foam core absorbs shock and flexing for reliability against wind and thermal stress
- UL GREENGUARD and UL GREENGUARD Gold Certified for sustainable building practices
- Bonds to broad range of substrates including metals, glass, composites, plastics and concrete
Technical Specifications
| Specification |
Value |
| Product Name | 3M VHB Architectural Panel Tape G11F |
| Product Number | G11F |
| 3M ID | 7100042406 |
| Color | Gray |
| Thickness | 0.045 inches (1.1 mm) |
| Core Material | Multi-purpose acrylic foam |
| Adhesive Type | Acrylic pressure-sensitive |
| Liner Material | Polyethylene Film |
| Core Size | 3 inches |
| Application Type | Architectural Panel |
| Industries | Construction, Architectural |
| Brand | VHB™ |
| Certifications | UL GREENGUARD and UL GREENGUARD Gold Certified |
| Smallest Saleable Unit | Roll |
| Temperature Resistance | Extreme temperatures from hot to cold climates |
| Recommended Applications | Architectural panels for curtain walls, exterior building cladding, interior panel and trim attachment |
| Substrate Compatibility | Aluminum, stainless steel, galvanized steel, composites, plastics, acrylic, polycarbonate, ABS, painted or sealed wood and concrete |
| Key Properties | Viscoelastic properties, shock absorption, flexing tolerance, water and moisture resistance |
Order 3M VHB Architectural Panel Tape G11F Gray 45 mil at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
