Premium black VHB architectural panel tape with 0.045 in foam core for permanent bonding of building cladding, curtain walls, and interior trim. Pressure-sensitive adhesive bonds instantly without fasteners, offering high strength, durability, and environmental resistance. UL GREENGUARD certified.
The 3M VHB Architectural Panel Tape B11F is a premium black, 0.045 inch (1.1 mm) thick multi-purpose acrylic adhesive tape featuring a conformable foam core and polyethylene film liner. This innovative bonding solution has been trusted by architects and builders for over 30 years in iconic buildings worldwide, including the Walt Disney Concert Hall. The tape provides a fast and easy-to-use permanent bonding method that delivers exceptional high strength and long-term durability without visible fasteners, making it an ideal alternative to structural silicone, spacer tapes, gaskets, screws, rivets, and welds.
Designed specifically for architectural applications, the VHB B11F tape excels in building cladding, curtain wall panels, and interior trim attachment. Its viscoelastic acrylic adhesive chemistry ensures reliable bonding to a broad range of substrates including aluminum, stainless steel, galvanized steel, composites, plastics, acrylic, polycarbonate, ABS, and painted or sealed wood and concrete. The pressure-sensitive adhesive bonds on contact with no drying time or fixturing required, providing immediate handling strength and allowing for faster assembly compared to traditional fastening methods.
The tape creates a permanent seal against water, moisture, and environmental elements while maintaining chemical resistance and UV and temperature stability. With UL GREENGUARD and UL GREENGUARD Gold Certification, this product contributes to LEED credits and sustainable building practices. The VHB B11F offers excellent shear strength, conformability, surface adhesion, and temperature resistance, making it suitable for use from the extreme heat of Dubai to the cold of Canada. This industrial-grade tape is intended for occupational and industrial use only and is not for consumer sale or use.
Key Features
- Fast and easy-to-use permanent bonding method with high strength and long-term durability
- Virtually invisible fastening keeps surfaces smooth and aesthetically pleasing
- Pressure-sensitive adhesive bonds on contact with immediate handling strength
- Creates permanent seal against water, moisture, and environmental elements
- Bonds to wide range of substrates including metals, glass, composites, and plastics
- UL GREENGUARD and UL GREENGUARD Gold Certified for sustainable building
- Chemical resistant with UV and temperature stability from extreme heat to cold
- Proven reliability used in iconic buildings for over 30 years
- Eliminates need for screws, rivets, welds, and mechanical fasteners
- Allows use of thinner, lighter weight and dissimilar materials
Technical Specifications
| Specification |
Value |
| Product Number | B11F |
| 3M ID | B40065778 |
| Adhesive Type | Acrylic |
| Product Color | Black |
| Total Tape Thickness without Liner | 0.045 in (1.143 mm) |
| Foam Type | Conformable |
| Core Size | 3 in |
| Liner Material | Polyethylene Film |
| Application | Architectural Panel |
| Brand | VHB™ |
| Industry | Construction |
| Substrate Compatibility | Aluminum, stainless steel, galvanized steel, composites, plastics, acrylic, polycarbonate, ABS, painted/sealed wood and concrete |
| Temperature Resistance | Extreme heat to extreme cold environments |
| Certifications | UL GREENGUARD, UL GREENGUARD Gold, LEED Credit eligible |
| Intended Use | Industrial/occupational use only - not for consumer sale or use |
Order 3M VHB Architectural Panel Tape B11F Black Foam at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
