Description

Shop 3M Tabbing and Splicing Tape 5699 Clear 0.625 inch In Iraq Best Prices

Premium pressure-sensitive tabbing and splicing tape with silicone adhesive for automotive trim attachment, featuring 0.10 mm thickness and high tack strength for efficient production applications.

3M™ Tabbing and Splicing Tape 5699 is a premium pressure-sensitive adhesive-backed film specifically engineered for automotive exterior trim attachment applications. This clear tape features a silicone adhesive applied to a polyester backing, providing a strong bond to the liners of 3M™ Acrylic Plus Tapes while enabling easy liner removal in production environments. With a thickness of 0.10 mm and width of 0.625 inches, this tape delivers consistent performance across manual and semi-automated applications. The tape offers exceptional high tack and good strength characteristics, making it ideal for efficient manual applications without requiring special equipment. Its robust design allows for versatile tabbing and splicing solutions, with tabs performing best when positioned at an angle over corners for enhanced functionality. The product is available in standard widths up to 1200 mm (48 inches) for compatibility with different production requirements, ensuring flexibility in various manufacturing environments. Designed for use with 3M™ Acrylic Plus Tape systems, this tabbing and splicing tape provides a reliable means of liner removal and attachment in automotive production. The undertab capability, achieved by placing the tab between the liner and tape, creates a more robust tabbing solution for demanding applications. This single-sided adhesive tape with rubber/resin formulation ensures optimal performance in temperature-sensitive and high-stress automotive exterior applications.

Key Features

Strong bond to liners of 3M Acrylic Plus Tapes for automotive exterior trim attachment
Silicone adhesive on polyester backing for easy liner removal in production environments
High tack and good strength for efficient manual applications without special equipment
Clear, 0.10 mm thickness compatible with various materials and applications
Available in standard widths up to 1200 mm (48 inches) for flexible production requirements
Undertab capability for more robust tabbing solutions
Optimal performance when tabs positioned at angle over corners
Single-sided adhesive application for precise positioning

Technical Specifications

Specification	Value
Product Number	5699
3M ID	7010394414
UPC Code	00051115555763
Overall Width (Imperial)	0.625 inches
Overall Width (Metric)	15.875 mm
Total Tape Thickness without Liner (Imperial)	0.004 inches
Total Tape Thickness without Liner (Metric)	0.1 mm
Product Color	Transparent/Clear
Adhesive Type	Rubber/Resin with Silicone
Number of Adhesive Sides	Single-sided
Backing Material	Polyester
Length	72 yards
Maximum Available Width	1200 mm (48 inches)
Brand	3M™
Application	Automotive Exterior Trim Attachment

Order 3M Tabbing and Splicing Tape 5699 Clear 0.625 inch at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.

3M Tabbing and Splicing Tape 5699 Clear 0.625 inch
