Professional-grade tabbing and splicing tape with silicone adhesive and polyester backing for automotive trim attachment. Clear, 0.10 mm thickness, 1.5 inch width, 72-yard roll for efficient production applications.
3M™ Tabbing and Splicing Tape 5699 is a premium pressure-sensitive adhesive-backed film specifically engineered for automotive exterior trim attachment applications. This specialized tape provides a strong, reliable bond to the liners of 3M™ Acrylic Plus Tapes, ensuring efficient liner removal in high-volume production environments. The tape features a silicone adhesive applied to a durable polyester backing, delivering exceptional performance characteristics for demanding manufacturing operations.
With a thickness of 0.10 mm and width of 1.5 inches, this clear tabbing and splicing tape offers high tack and excellent strength to liners, making it ideal for both manual and automated applications. The tape is available in standard widths up to 1200 mm (48 inches) for compatibility with various production requirements and equipment configurations. Its transparent color allows for easy visibility during application and positioning, while the pressure-sensitive adhesive eliminates the need for special equipment or heat activation.
The 3M™ Tabbing and Splicing Tape 5699 performs optimally when tabs are positioned at an angle over corners for enhanced functionality and holding strength. The product supports undertab placement by positioning the tab between the liner and tape for a more robust tabbing solution. With a 72-yard roll length, this tape is engineered for professional automotive manufacturing, trim attachment, and precision splicing applications where reliability and performance are paramount.
Key Features
- Strong bond to liners of 3M™ Acrylic Plus Tapes for automotive exterior trim attachment
- Silicone adhesive applied to polyester backing for easy liner removal in production environments
- High tack and excellent strength to liners for efficient manual and automated applications
- Clear transparent color for easy visibility during application and positioning
- Pressure-sensitive adhesive eliminates need for special equipment or heat activation
- Supports corner tab positioning and undertab placement for enhanced functionality
- Available in standard widths up to 1200 mm (48 inches) for production compatibility
Technical Specifications
| Specification |
Value |
| Product Number | 5699 |
| 3M ID | 7010291894 |
| UPC | 00051115555930 |
| Overall Width (Imperial) | 1.5 inches |
| Overall Width (Metric) | 38.1 mm |
| Total Tape Thickness without Liner (Imperial) | 0.004 inches |
| Total Tape Thickness without Liner (Metric) | 0.1 mm |
| Roll Length | 72 yards |
| Product Color | Transparent/Clear |
| Adhesive Type | Rubber/Resin with Silicone |
| Backing Material | Polyester |
| Number of Adhesive Sides | Single-sided |
| Brand | 3M™ |
| Application | Automotive exterior trim attachment, tabbing and splicing |
| Maximum Available Width | 1200 mm (48 inches) |
| Inventory Availability | 5 Days |
