Premium 10 mil PVC corrosion protection tape with extreme temperature resistance (-55°F to 176°F), high-tack rubber adhesive, and UV resistance. Ideal for industrial piping, conduits, and electrical systems in construction, mining, and utility industries.
3M™ Scotchrap™ Vinyl Corrosion Protection Tape 50 is a premium-grade, all-weather protective tape designed for industrial applications requiring superior corrosion resistance. This 10 mil thick tape features a flexible PVC backing with a high-tack rubber adhesive that withstands extreme temperatures ranging from -55°F to 176°F (-48°C to 80°C). The tape provides exceptional resistance to corrosion, impact, abrasion, and puncture damage, making it ideal for protecting metal piping systems, conduits, and fittings both above and below ground in demanding industrial environments.
The Scotchrap Tape 50 offers excellent tacking and high conformability with its pressure-sensitive rubber adhesive formulation. Its flexible PVC backing delivers both mechanical strength and electrical insulation properties, ensuring reliable protection in diverse applications. The tape is highly resistant to UV rays, corrosive salt water, soil acids, alkalis, salts, and various chemicals, maintaining its protective properties under varying weather conditions. It performs effectively on straight pipes, conduits, and field joints on mill-coated pipes, making it suitable for maintenance and repair of electrical systems across construction, irrigation, mining, utility, and energy industries.
Each case contains 10 rolls of unprinted black tape, with each roll measuring 1 inch wide by 100 feet long. The product meets RoHS 2011/65/EU specifications and is manufactured in the USA. This professional-grade corrosion protection tape is engineered for industrial and occupational use only, delivering reliable performance in the most challenging environmental conditions.
Key Features
- Extreme temperature adhesive withstands -55°F to 176°F (-48°C to 80°C)
- High-tack rubber adhesive offers resistance to corrosion, impact, abrasion and puncture
- Highly resistant to UV rays, soil acids, alkalis, salts, chemicals and weather conditions
- Flexible PVC backing provides mechanical strength and electrical insulation properties
- Professional-grade performance for industrial piping, conduits and field joints
- RoHS 2011/65/EU compliant with 5-year shelf life
- Pressure-sensitive adhesive ensures excellent tacking and high conformability
- Effective on both above and below ground applications
Technical Specifications
| Specification |
Value |
| Product Name | 3M Scotchrap Vinyl Corrosion Protection Tape 50 |
| Part Number | 50UP-1X100FT |
| 3M ID | 7000057501 |
| UPC Code | 00054007111498 |
| Overall Width (Imperial) | 1 in |
| Overall Width (Metric) | 25.4 mm |
| Overall Length (Imperial) | 100 ft |
| Overall Length (Metric) | 30.5 m |
| Total Tape Thickness (Imperial) | 10 mil |
| Total Tape Thickness (Metric) | 0.3 mm |
| Backing Thickness (Imperial) | 9.8 mil |
| Backing Thickness (Metric) | 0.25 mm |
| Overall Thickness (Imperial) | 0.01 in |
| Overall Thickness (Metric) | 0.25 mm |
| Adhesive Type | Rubber |
| Backing Material | PVC |
| Adhesion Strength (Imperial) | 20 oz/in |
| Adhesion Strength (Metric) | 21.9 N/100mm |
| Elongation at Break | 200% |
| Minimum Operating Temperature (Fahrenheit) | -55°F |
| Minimum Operating Temperature (Celsius) | -48°C |
| Maximum Operating Temperature (Fahrenheit) | 176°F |
| Maximum Operating Temperature (Celsius) | 80°C |
| Minimum Installation Temperature (Fahrenheit) | 10°F |
| Minimum Installation Temperature (Celsius) | -12°C |
| Maximum Installation Temperature (Fahrenheit) | 150°F |
| Maximum Installation Temperature (Celsius) | 65°C |
| Application | Corrosion Protection |
| Tape Type | Corrosion Protection |
| Performance Level | Professional Grade |
| Brand | Scotchrap |
| Chemical Resistant | Yes |
| UV Resistant | Yes |
| Electrolytic Corrosion Factor | 0.9 |
| Features | Flame Retardant, UV-resistant |
| Shelf Life | 5 Year |
| Specifications Met | RoHS 2011/65/EU |
| Quantity per Case | 10 rolls |
| Color | Black |
| Printing | Unprinted |
| Manufacturing Origin | USA |
| Intended Use | Industrial/Occupational use only |
