Professional-grade black and white safety stripe vinyl tape with embedded color, rubber adhesive, and unique stretchability for industrial lane and hazard marking applications. 3-inch width, 36-yard length per roll, 12 rolls per case.
The 3M™ Safety Stripe Vinyl Tape 5700 is a professional-grade marking solution designed specifically for high-visibility safety applications in industrial environments. This durable black and white striped tape features embedded color technology that resists abrasion, scuffing, and moisture to maintain visibility even under harsh workplace conditions. The tape comes in a convenient 3-inch width with 36-yard length per roll, and each case contains 12 rolls for bulk application needs.
Engineered with unique stretchability properties, this vinyl tape conforms seamlessly to irregular, curved, and convex surfaces while maintaining tension without lifting or retracting after application. The rubber adhesive provides quick-stick capability and excellent holding strength on most surfaces, preventing edge lifting and ensuring long-term adhesion. The 5.4 mil thickness offers optimal durability while remaining flexible enough for complex surface applications.
Designed for lane and safety marking in factories, warehouses, hospitals, and public areas, this tape eliminates the need for time-consuming and costly paint applications. It removes cleanly in one piece from most surfaces, significantly reducing cleanup and labor costs. The color-embedded backing resists harsh solvents, acids, and alkaline chemicals, making it suitable for demanding industrial environments. With an 18-month shelf life and operating temperature range from 40°F to 170°F, this tape delivers reliable performance across diverse workplace applications.
Key Features
- Wear-resistant stripes with embedded color printed below surface to prevent rubbing off through normal wear
- Unique stretchability with slight elasticity conforms to uneven, curved, and convex surfaces without lifting
- Comes off clean with one-piece removal to minimize cleanup and labor costs
- Powerful rubber adhesive provides quick stick and excellent holding strength on most surfaces
- Long service life with construction that resists harsh solvents, acids, and alkaline chemicals
- Attention-grabbing black and white stripes for clear safety and hazard zone designation
- Quick application with minimal prep work compared to traditional paint marking methods
- Prevents edge lifting and maintains secure placement through superior adhesive and backing properties
Technical Specifications
| Specification |
Value |
| Product Name | 3M Safety Stripe Vinyl Tape 5700 |
| Part Number | 5700 |
| UPC Code | 00021200039546 |
| Color | Black and White |
| Overall Width (Imperial) | 3 inches |
| Overall Width (Metric) | 7.6 centimeters |
| Overall Length (Imperial) | 36 yards |
| Overall Length (Metric) | 32.91 meters |
| Total Tape Thickness without Liner (Imperial) | 5.4 mil |
| Total Tape Thickness without Liner (Metric) | 0.14 millimeters |
| Backing Carrier Material | Vinyl |
| Backing Carrier Thickness (Imperial) | 4.2 mil |
| Backing Carrier Thickness (Metric) | 0.11 millimeters |
| Adhesive Type | Rubber |
| Back Side Adhesive Thickness (Imperial) | 1.2 mil |
| Back Side Adhesive Thickness (Metric) | 0.11 millimeters |
| Tensile Strength (Imperial) | 240 oz/in |
| Tensile Strength (Metric) | 26 N/100mm |
| Elongation at Break | 170% |
| Minimum Operating Temperature (Fahrenheit) | 40°F |
| Minimum Operating Temperature (Celsius) | 4°C |
| Maximum Operating Temperature (Fahrenheit) | 170°F |
| Maximum Operating Temperature (Celsius) | 77°C |
| Application | Safety and Hazard Marking |
| Case Quantity | 12 rolls per case |
| Smallest Saleable Unit | Roll |
| Shelf Life | 18 months |
| Performance Level | High Performance |
| Specifications Met | D-3330, D-3652, D-3759 |
| Brand | 3M |
| Industries | Aerospace, Automotive, General Industrial, MRO, Marine, Military, Specialty Vehicles, Transportation |
