Professional-grade transparent polyester film tape with aggressive acrylic adhesive for solvent-resistant industrial applications. Ideal for aerospace, automotive, and electronics with exceptional chemical and temperature resistance.
3M™ Polyester Film Tape 853 is a high-performance transparent polyester film tape engineered for demanding industrial applications requiring solvent resistance and durability. Comprised of a thin yet strong polyester backing coated with an aggressive acrylic adhesive, this tape is specifically designed to withstand exposure to harsh chemicals including jet engine fuel, hydraulic fluid, and lubricating oils. The transparent backing allows visibility of information protected by the tape, making it ideal for critical label protection applications where obscuring vital information is not acceptable.
This professional-grade tape features exceptional tearing resistance and provides surface protection through its robust polyester backing. With a temperature operating range from -60°F/-50°C to 300°F/150°C, it performs reliably in high-temperature operations. The low moisture vapor transmission rate of the backing ensures extended durability in demanding environments. Each case contains 2 rolls of 360 yards each on plastic cores, providing substantial coverage for industrial operations. The tape meets several U.S. government and aerospace specifications, including FAR 25.853(a) Appendix F Part I (a)(1)(ii) flammability requirements, making it suitable for aerospace and military applications.
Ideal for critical applications in aerospace, automotive, electronics, and general industrial sectors, 3M Polyester Film Tape 853 delivers consistent performance in processes where solvent exposure and chemical resistance are paramount concerns. The quick-stick aggressive acrylic adhesive ensures excellent long-term holding power, while the durable polyester carrier resists tearing and abrasion. This tape can be qualified to meet Federal Spec. L-T-100 Type 1 and complies with multiple ASTM standards including D3330, D3652, and D3759.
Key Features
- Thin high-strength polyester backing resists tearing and protects surfaces from abrasion
- Transparent backing allows visibility of protected information without obscuring labels
- Resistant to jet engine fuel, hydraulic fluid, lubricating oils and many industrial solvents
- Temperature resistant from -60°F/-50°C to 300°F/150°C for high-temperature operations
- Aggressive acrylic adhesive provides quick stick and excellent long-term holding power
- Meets FAR 25.853(a) flammability requirements for aerospace applications
- Low moisture vapor transmission rate for extended durability in demanding environments
- Can be qualified to meet Federal Spec. L-T-100 Type 1 standards
- Complies with ASTM D3330, D3652, and D3759 specifications
- Ideal for critical label protection in aerospace, automotive, and electronics industries
Technical Specifications
| Specification |
Value |
| Product Number | 853 |
| UPC Code | 00051111921692 |
| 3M ID | 7010045194 |
| Overall Width (Imperial) | 5.25 in |
| Overall Width (Metric) | 133.35 mm |
| Overall Length (Imperial) | 360 yd |
| Overall Length (Metric) | 329.18 m |
| Total Tape Thickness without Liner (Imperial) | 2.2 mil |
| Total Tape Thickness without Liner (Metric) | 0.06 mm |
| Backing (Carrier) Material | Polyester |
| Backing (Carrier) Thickness (Imperial) | 1.1 in |
| Backing (Carrier) Thickness (Metric) | 0.03 mm |
| Product Color | Transparent |
| Adhesive Type | Acrylic |
| Minimum Operating Temperature (Fahrenheit) | -60 ℉ |
| Minimum Operating Temperature (Celsius) | -50 ℃ |
| Maximum Operating Temperature (Fahrenheit) | 300 ℉ |
| Tensile Strength (Imperial) | 25 lb/in |
| Tensile Strength (Metric) | 43.4 N/100mm |
| Elongation at Break | 83% |
| Units per Case | 2 Rolls |
| Smallest Saleable Unit | Roll |
| Core Type | Plastic Core |
| Application | General Industrial |
| Specifications Met | ASTM D3330, ASTM D3652, ASTM D3759, Federal Spec. L-T-100 Type 1, FAR 25.853(a) Appendix F Part I (a)(1)(ii) |
| Brand | 3M™ |
| Industries | Appliance, Automotive, Construction, Electronics, General Industrial, Military & Government, Print, Specialty Vehicles, Transportation |
