Premium soft gripping material with micro-replicated fingers for superior grip and slip resistance. Acrylic pressure-sensitive adhesive bonds to multiple surfaces. Temperature range -40°F to 140°F with excellent UV resistance.
3M™ Gripping Material GMP641 is a premium soft, adhesive-backed gripping material engineered to provide superior grip and slip resistance across a wide range of industrial applications. Constructed with thousands of micro-replicated gripping fingers, this innovative material delivers a lighter yet tighter grip for maximum hold with minimum effort. The material features an acrylic pressure-sensitive adhesive specifically designed to bond to a wide variety of surfaces, including low surface energy substrates such as plastics and powder-coated paints. This peel-and-stick product offers quick and easy application without requiring special tools or equipment.
The GMP641 gripping material is manufactured with a soft thermoplastic elastomer polymer that provides exceptional high friction properties combined with increased cushioning, comfort, flexibility, and softness. When mated with another gripping material, it delivers outstanding coefficient of friction properties even in wet conditions, making it ideal for both indoor and outdoor applications. The material boasts excellent UV sunlight resistance, making it particularly suitable for exterior applications and environments exposed to direct sunlight. With a temperature operating range from -40°F to 140°F (-40°C to 60°C), this gripping material performs reliably in diverse climate conditions.
Typically outlasting leather in factory and field environments, the 3M™ Gripping Material GMP641 can be shear cut, die-cut, laser cut, or converted using other applicable methods. The product is available in roll form with a polyester film backing and is recommended for equipment handles, levers, grips on industrial equipment and tools, truck and forklift steering wheels, power tools, gardening equipment, and sports equipment handles. This industrial-grade material is backed by 3M's commitment to quality and performance, making it an essential component for any application requiring enhanced grip and slip resistance.
Key Features
- Micro-replicated gripping fingers technology for enhanced grip and reduced slippage
- Soft thermoplastic elastomer provides high friction with cushioning and comfort
- Acrylic pressure-sensitive adhesive bonds to wide variety of surfaces including low surface energy substrates
- High coefficient of friction properties even in wet conditions when mated with another gripping material
- Excellent UV sunlight resistance suitable for exterior and outdoor applications
- Wide temperature operating range from -40°F to 140°F (-40°C to 60°C)
- Peel-and-stick application for quick and easy installation without special tools
- Outlasts leather in factory and field environments
- Can be shear cut, die-cut, laser cut or converted by other applicable methods
- Slip resistance and easy-release properties for maximum versatility
Technical Specifications
| Specification |
Value |
| Part Number | GMP641 |
| 3M Product Number | GM641 |
| 3M ID | 7100132978 |
| Product Color | Black |
| Total Tape Thickness without Liner (Metric) | 0.97 mm |
| Total Tape Thickness without Liner (Imperial) | 38 mil |
| Backing (Carrier) Material | Polyester Film |
| Backing (Carrier) Thickness (Metric) | 0.08 mm |
| Backing (Carrier) Thickness (Imperial) | 4 mil |
| Tensile Strength (Imperial) | 379 oz/in |
| Tensile Strength (Metric) | 49.3 kg |
| Elongation at Break | 55% |
| Minimum Operating Temperature (Fahrenheit) | -40 ℉ |
| Minimum Operating Temperature (Celsius) | -40 ℃ |
| Maximum Operating Temperature (Fahrenheit) | 140 ℉ |
| Maximum Operating Temperature (Celsius) | 60 ℃ |
| Adhesive Type | Acrylic Pressure Sensitive Adhesive |
| Gripping Polymer | Soft Thermoplastic Elastomer |
| Shelf Life | 18 Months |
| Smallest Saleable Unit | Roll |
| Brand | 3M™ |
| Specifications Met | ASTM D1388, ASTM D2240, ASTM D5035 |
| Application Method | Peel and Stick |
| UV Resistance | Excellent - Best UV sunlight resistance among gripping material products |
| Surface Compatibility | Bonds to wide variety of surfaces including low surface energy plastics and powder coated paints |
