Professional 3M double coated tissue tape with 340 high tack acrylic adhesive, 5 mil thickness, 54-inch width. Superior adhesion to HSE materials with excellent temperature, chemical and humidity resistance for industrial bonding applications.
3M™ Double Coated Tissue Tape 9456 is a professional-grade adhesive solution featuring a 5.0 mil tape with 340 high tack acrylic adhesive designed for superior bonding performance. This industrial tape combines excellent adhesion to high surface energy (HSE) materials with dimensional stability through its tissue carrier construction. The tape delivers consistent bonding performance across a wide temperature range from -40°F to 150°F (-40°C to 66°C), making it suitable for demanding industrial applications.
The 3M Adhesive 340 technology provides a combination of high initial adhesion, excellent shear strength, and superior holding power when applied to various materials including plastics, foams, fabrics, and rigid substrates. The 55# densified Kraft paper liner (3.2 mil thickness) ensures compatibility with rotary die cutting equipment while maintaining the flexibility of a free film adhesive. This versatile tape offers outstanding chemical and thermal resistance, making it ideal for applications requiring long-term durability and reliability.
With a transparent color and 54-inch (137 cm) overall width, the 3M Double Coated Tissue Tape 9456 is engineered for end-tabbing, foam-to-plastic bonding, fabric-to-cardboard attachment, and general industrial joining applications. The tape's proven performance across multiple industries including automotive, medical, packaging, and general manufacturing makes it a trusted choice for professional converters and industrial users seeking premium adhesive solutions.
Key Features
- 5 mil double coated tape with tissue carrier for dimensional stability and superior handling
- High tack acrylic adhesive (340) delivers excellent initial adhesion and shear strength
- Good adhesion to high surface energy (HSE) materials including plastics, foams, and fabrics
- Wide temperature range: -40°F to 150°F (-40°C to 82°C) for demanding applications
- 55# densified Kraft paper liner compatible with rotary die cutting equipment
- Excellent chemical, thermal and humidity resistance for long-term durability
- Transparent color for invisible bonding applications
- Suitable for end-tabbing, foam bonding, fabric attachment and industrial joining
Technical Specifications
| Specification |
Value |
| Part Number | 9456 |
| Product Form | Roll |
| Overall Width (Imperial) | 54 inches |
| Overall Width (Metric) | 137 centimeters |
| Total Tape Thickness without Liner (Imperial) | 4 mil |
| Total Tape Thickness without Liner (Metric) | 0.1 millimeters |
| Face Side Adhesive Thickness (Imperial) | 2 mil |
| Face Side Adhesive Thickness (Metric) | 0.05 millimeters |
| Back Side Adhesive Thickness (Imperial) | 2 mil |
| Back Side Adhesive Thickness (Metric) | 0.051 millimeters |
| Adhesive Type | High Tack Acrylic Adhesive 340 |
| Backing Material | Tissue |
| Primary Liner | 55# Densified Kraft Paper (DK) |
| Primary Liner Color | White |
| Primary Liner Thickness (Imperial) | 3.5 mil |
| Primary Liner Thickness (Metric) | 0.09 millimeters |
| Product Color | Transparent |
| Minimum Operating Temperature (Fahrenheit) | -40°F |
| Minimum Operating Temperature (Celsius) | -40°C |
| Maximum Operating Temperature (Fahrenheit) | 180°F |
| Maximum Operating Temperature (Celsius) | 82°C |
| Indoor/Outdoor Use | Indoor/Outdoor |
| Smallest Saleable Unit | Roll |
| Brand | 3M™ |
| 3M Product Number | 9456 |
| 3M ID | 7100012208 |
| Industries | Automotive, Converter Solutions, General Industrial, Medical, Packaging, Paper, Point of Purchase, Print, Retail |
| Recommended Applications | End-tabbing, Bonding fabric to rigid cardboard, Attaching foam to plastics, Closing chipboard mailers, Joining and bonding in general industrial applications |
| Surface Compatibility | High Surface Energy (HSE) Materials |
| Chemical Resistance | Excellent |
