High-tack acrylic double coated tissue tape with 3M Adhesive 340 for industrial bonding applications. Features dimensional stability, excellent temperature and chemical resistance (-40°F to 150°F), and superior adhesion to HSE materials. 24 rolls per case, 72 yards each, 2 inches wide.
3M™ Double Coated Tissue Tape 9456 is a premium high-tack acrylic adhesive tape specifically engineered for industrial bonding applications. This 5 mil double coated tape features a tissue carrier that provides dimensional stability and improved handling while maintaining the flexibility of a free film adhesive. The tape utilizes 3M's proprietary Adhesive 340 technology, which delivers exceptional initial adhesion, superior shear strength, and reliable holding power when applied to high surface energy (HSE) materials including plastics, foams, and various substrates.
The product is designed for a wide range of demanding industrial applications including end-tabbing, bonding fabric to rigid cardboard, attaching foam to plastics, and closing chipboard mailers. With a 3.2 mil 55-lb densified Kraft (DK) paper liner and transparent product color, this tape offers excellent chemical and thermal resistance. It maintains optimal performance across an extended temperature range from -40°F (-40°C) to 150°F (66°C), making it suitable for both indoor and outdoor industrial environments.
Each case contains 24 rolls of 72 yards (65.83 meters) with a 2-inch (50.8mm) width, providing ample supply for production facilities and converter operations. The tape's compatibility with rotary die cutting equipment and its proven performance across automotive, medical, packaging, paper, and general industrial sectors make it an industry-standard solution for manufacturers seeking reliable bonding solutions.
Key Features
- 5 mil double coated tape with tissue carrier for dimensional stability and improved handling
- High tack acrylic adhesive (3M Adhesive 340) with exceptional initial adhesion and shear strength
- Excellent adhesion to high surface energy (HSE) materials including plastics, foams, and rigid substrates
- Superior temperature, chemical, and humidity resistance across -40°F to 150°F operating range
- 55# densified kraft paper liner compatible with rotary die cutting equipment for automated processing
- Indoor/outdoor rated with proven performance in automotive, medical, packaging, and industrial applications
- Transparent clear color for aesthetic applications and visual inspection
- 24 rolls per case configuration for production efficiency and cost effectiveness
Technical Specifications
| Specification |
Value |
| Part Number | 9456 |
| Product Type | Double Coated Tissue Tape |
| Adhesive Type | High Tack Acrylic Adhesive 340 |
| Overall Width (Imperial) | 2 inches |
| Overall Width (Metric) | 50.8 millimeters |
| Overall Length (Imperial) | 72 yards |
| Overall Length (Metric) | 65.83 meters |
| Total Tape Thickness without Liner (Imperial) | 4 mil |
| Total Tape Thickness without Liner (Metric) | 0.1 millimeter |
| Face Side Adhesive Thickness (Imperial) | 2 mil |
| Face Side Adhesive Thickness (Metric) | 0.05 millimeter |
| Back Side Adhesive Thickness (Imperial) | 2 mil |
| Back Side Adhesive Thickness (Metric) | 0.051 millimeter |
| Backing (Carrier) Material | Tissue |
| Primary Liner Material | 55# Densified Kraft Paper (DK) |
| Primary Liner Color | White |
| Primary Liner Thickness (Imperial) | 3.5 mil |
| Primary Liner Thickness (Metric) | 0.09 millimeter |
| Product Color | Transparent Clear |
| Product Form | Roll |
| Minimum Operating Temperature (Fahrenheit) | -40°F |
| Minimum Operating Temperature (Celsius) | -40°C |
| Maximum Operating Temperature (Fahrenheit) | 180°F |
| Maximum Operating Temperature (Celsius) | 82°C |
| Indoor/Outdoor Rating | Indoor/Outdoor |
| Units per Case | 24 rolls |
| Smallest Saleable Unit | Roll |
| UPC Code | 00021200443299 |
| 3M ID | 7000123901 |
| Brand | 3M™ |
| Key Applications | End-tabbing, fabric bonding, foam attachment, chipboard mailers, general industrial bonding |
| Compatible Industries | Automotive, Converter Solutions, General Industrial, Medical, Packaging, Paper, Point of Purchase, Print, Retail |
