| Part Number | 9828 |
| Product Form | Roll |
| Overall Width (Imperial) | 54 inches |
| Overall Width (Metric) | 137 centimeters |
| Total Tape Thickness without Liner (Imperial) | 3.3 mil |
| Total Tape Thickness without Liner (Metric) | 0.084 millimeters |
| Backing (Carrier) Material | Polyester Film |
| Carrier Thickness (Imperial) | 0.5 mil |
| Carrier Thickness (Metric) | 0.013 millimeters |
| Adhesive Type | Acrylic (High Tack Adhesive 340) |
| Back Side Adhesive Thickness (Imperial) | 1.5 mil |
| Back Side Adhesive Thickness (Metric) | 0.038 millimeters |
| Face Side Adhesive Thickness (Imperial) | 2 mil |
| Face Side Adhesive Thickness (Metric) | 0.051 millimeters |
| Number of Adhesive Sides | Double-sided |
| Product Color | Transparent/Clear |
| Primary Liner | 55# Densified Kraft Paper (White) |
| Primary Liner Thickness (Imperial) | 3.2 mil |
| Primary Liner Thickness (Metric) | 0.08 millimeters |
| Core Size (Imperial) | 3 inches |
| Core Size (Metric) | 76.2 millimeters |
| Master Size Length (Imperial) | 180 Linear Yards |
| Master Size Length (Metric) | 164.6 meters |
| Maximum Operating Temperature (Fahrenheit) | 120°F |
| Maximum Operating Temperature (Celsius) | 49°C |
| Minimum Operating Temperature (Fahrenheit) | -40°F |
| Minimum Operating Temperature (Celsius) | -40°C |
| Indoor/Outdoor Use | Both |
| Automotive OEM Specification | Ford WSS-M11P62 |
| Suitable Industries | Automotive, Medical Devices, Packaging, General Industrial, Electronics, Aerospace |
| Recommended Applications | Foam lamination, Gasket attachment, Fabricated parts lamination |
| Smallest Saleable Unit | Roll |
| Brand | 3M™ |
| 3M Product Number | 9828 |
| 3M ID | 7100013285 |
| Use Classification | Industrial/Occupational Use Only - Not for Consumer Sale |
