Professional 3M double-sided splicing tape with high-tack acrylic adhesive, polyester carrier, excellent temperature performance up to 300°F, and superior adhesion for industrial web processing applications.
The 3M™ Double Coated Tape 9737 is a professional-grade double-sided tape specifically engineered for high-speed splicing applications in industrial settings. This premium tape features a thin polyester carrier with a pressure-sensitive acrylic adhesive that delivers an optimal balance of high initial adhesion and excellent holding power. Mounted on a 55 lb. densified kraft paper liner, this 3.5 mil thick tape ensures easy release and precise manipulation during application, making it ideal for demanding web processing environments.
Designed for versatility and reliability, the 3M Double Coated Tape 9737 performs exceptionally well across a broad temperature range, with short-term capabilities up to 300°F (149°C) and sustained performance up to 260°F (127°C) for extended periods. The high-tack acrylic adhesive bonds excellently to kraft and coated papers, as well as plastic materials, providing superior peel, tack, and shear strength that withstands rigorous splicing applications. This industrial-strength tape is available in both clear and red options, with the red variant offering enhanced visibility for critical splicing operations.
Each case contains 24 rolls of 55-meter length tape, providing substantial coverage for continuous production operations. The tape's excellent moisture resistance ensures consistent performance across various environmental conditions and applications. Whether used for high-speed flying splices, zero-speed splices, core starting, or splicing films, foils, and corrugated paper, the 3M Double Coated Tape 9737 delivers professional-grade results that industrial users can depend on.
Key Features
- High-tack acrylic adhesive with excellent peel, tack, and shear strength for rigorous splicing applications
- Thin polyester carrier mounted on 55 lb. densified kraft paper liner for easy release and manipulation
- Superior temperature performance with short-term capability to 300°F (149°C) and sustained performance to 260°F (127°C)
- Double-sided adhesive design ideal for high-speed flying splices, zero-speed splices, and core starting applications
- Excellent moisture resistance and strong adhesion to kraft papers, coated papers, and plastic materials
- Available in clear and red options with red variant providing enhanced visibility for critical operations
- 24 rolls per case with 55-meter length per roll for substantial production coverage
- Versatile application suitability for films, foils, corrugated paper, and continuous web processes
Technical Specifications
| Specification |
Value |
| Product Type | Double Coated Splicing Tape |
| Brand | 3M |
| Model Number | 9737 |
| 3M Product Number | 9737R |
| 3M ID | 7000029048 |
| UPC Code | 00051115314650 |
| Overall Width (Metric) | 48 mm |
| Overall Width (Imperial) | 1.9 inches |
| Overall Length (Metric) | 55 meters |
| Overall Length (Imperial) | 60.15 yards |
| Total Tape Thickness without Liner (Metric) | 0.089 mm |
| Total Tape Thickness without Liner (Imperial) | 3.5 mil |
| Backing/Carrier Material | Polyester Film |
| Carrier Thickness (Imperial) | 0.5 mil |
| Carrier Thickness (Metric) | 0.0127 mm |
| Adhesive Type | Pressure-Sensitive Acrylic |
| Number of Adhesive Sides | Double-sided |
| Primary Liner | 55# Densified Kraft Paper |
| Primary Liner Color | White |
| Product Color | Transparent |
| Product Form | Roll |
| Maximum Operating Temperature (Fahrenheit) | 300°F |
| Maximum Operating Temperature (Celsius) | 149°C |
| Sustained Operating Temperature | 260°F (127°C) for days or weeks |
| Units per Case | 24 rolls |
| Application Type | Zero-Speed and General Splicing |
| Tape Type | Double Coated |
| Industries | Appliance, Automotive, Electronics, General Industrial, Medical, Specialty Vehicles, Transportation |
| Recommended Applications | High-speed flying splices, Zero-speed splices, Core starting, Splicing films, foils and corrugated paper |
| Surface Compatibility | Kraft and coated papers, plastic materials |
| Key Features | High tack, excellent peel and shear strength, good moisture resistance, easy release and manipulation |
| Use Restrictions | For industrial/occupational use only. Not for consumer sale or use. |
