Premium double coated adhesive tape with 2.0 mil thickness, PET carrier, and Quick Bonding Adhesive 360 for immediate bonding to high and low surface energy materials with exceptional strength and chemical resistance.
3M™ Double Coated Tape 9628FL is a premium industrial adhesive solution engineered for immediate bonding to high and low surface energy materials. Featuring a clear, 2.0 mil (0.05 mm) double coated construction on a PET polyester carrier with PET polyester film liner, this tape delivers exceptional strength from thin bond lines. The tape incorporates 3M™ Quick Bonding Adhesive 360, providing high bond strength with minimal adhesive application, resulting in a strong yet light and smooth finish ideal for precision applications.
Designed for quick stick adhesion and immediate bond formation, 3M™ Double Coated Tape 9628FL offers outstanding adhesion properties that bond exceptionally well to hard-to-stick-to materials including polypropylene and powder-coated paints. The tape demonstrates excellent resistance to humidity, UV exposure, water, and short-term temperatures up to 250°F (121°C), along with resistance to various chemicals including oils, mild acids, and alkalis. The double coated format provides ease of die-cutting and laminating applications, making it ideal for precision manufacturing environments.
This industrial-grade tape is recommended for plastic housing and component assembly applications such as bezel bonding, interior decorative trim attachment, and badge and logo mounting. The PET polyester film liner provides superior dimensional stability and improved handling characteristics, ensuring consistent performance across diverse manufacturing processes. For industrial and occupational use only, this product is engineered to meet the demanding requirements of aerospace, automotive, electronics, medical device, and general industrial applications.
Key Features
- Clear, 2.0 mil (0.05 mm) double coated tape with PET polyester carrier and film liner
- Quick stick adhesion with immediate bond formation for efficient assembly processes
- Exceptional adhesion to high and low surface energy plastics including polypropylene
- Superior resistance to humidity, UV, water, and temperatures up to 250°F (121°C)
- Chemical resistant to oils, mild acids, alkalis, and solvents with minimal oozing
- Double coated format enabling ease of die-cutting and laminating applications
- Dimensional stability and improved handling with PET polyester film liner
- High bond strength with minimal adhesive for thin, light bond lines
- Bonds well to powder-coated paints and hard-to-stick-to substrates
- Industrial-grade performance for aerospace, automotive, electronics, and medical applications
Technical Specifications
| Specification |
Value |
| Product Number | 9628FL |
| 3M ID | 7100000239 |
| Adhesive Type | Acrylic (Quick Bond Acrylic Adhesive 360) |
| Backing Material | PET Polyester |
| Backing Thickness | 0.5 mil (0.013 mm) |
| Face Side Adhesive Thickness | 0.75 mil (0.019 mm) |
| Back Side Adhesive Thickness | 0.75 mil (0.019 mm) |
| Total Tape Thickness without Liner | 2.0 mil (0.05 mm) |
| Primary Liner Material | PET Polyester |
| Primary Liner Color | Transparent |
| Primary Liner Thickness | 2.0 mil (0.05 mm) |
| Product Color | Transparent/Clear |
| Maximum Operating Temperature | 350°F (177°C) |
| Minimum Operating Temperature | -40°F (-40°C) |
| Short-Term Temperature Resistance | Up to 250°F (121°C) |
| Chemical Resistance | Oils, mild acids, alkalis, and solvents |
| Environmental Resistance | Humidity, UV, and water resistant |
| Smallest Saleable Unit | Roll |
| Brand | 3M™ |
| Industries | Aerospace, Automotive, Converter Solutions, Electronics, General Industrial, Medical, Specialty Vehicles, Transportation, Woodworking |
| Recommended Applications | Plastic housing assembly, bezel bonding, interior decorative trim, badge and logo attachment |
| Format | Double coated with PET polyester carrier and film liner |
