Premium industrial double coated tape with dual liners for selective die cutting, featuring 300LSE acrylic adhesive for exceptional bonding to LSE plastics, foam, and powder-coated surfaces. 24x36 inch sheets, 6.7 mil thickness, case of 100.
3M™ Double Coated Tape 9474LE is a premium industrial adhesive tape featuring dual liners for ease in selective die cutting and exceptional bonding performance. This clear polyester film carrier tape delivers high bond strength to low surface energy (LSE) plastics, foam substrates, and powder-coated painted surfaces. The tape utilizes 3M's advanced High Strength Acrylic Adhesive 300LSE, which offers very high initial adhesion and excellent chemical and solvent resistance across a wide temperature range from -40°F to 300°F (-40°C to 149°C).
Designed specifically for industrial and occupational applications, this double coated tape provides excellent adhesion to surfaces contaminated lightly with oil, making it ideal for bonding machine parts and precision assembly work. The polyester film carrier adds dimensional stability to foams and other flexible substrates, while the dual liner design enables precise application and selective die-cutting for custom shapes. Each case contains 100 sheets of 24 x 36 inch tape with a total thickness of 6.7 mil without liner, providing consistent performance across high-volume manufacturing operations.
This tape is recommended for foam to powder coated painted surface bonding, low surface energy plastic adhesion, lens and logo bonding applications, touchpad bracket assembly, battery bonding, and gasket attachment. The 3M Industrial Adhesives and Tapes Division has engineered this solution to help manufacturers deliver competitive products to market faster and more efficiently while maintaining superior bond quality and durability.
Key Features
- Dual liner design for ease in selective die cutting and precise application
- 3M High Strength Acrylic Adhesive 300LSE with very high initial adhesion
- Excellent adhesion to low surface energy (LSE) plastics and powder-coated surfaces
- Bonds effectively to surfaces contaminated lightly with oil and machine parts
- Polyester film carrier provides dimensional stability to foams and flexible substrates
- Chemical and solvent resistant with temperature range -40°F to 300°F (-40°C to 149°C)
- Clear color for aesthetic applications and visibility during assembly
- Industrial-grade quality for high-volume manufacturing operations
Technical Specifications
| Specification |
Value |
| Product Name | 3M™ Double Coated Tape 9474LE |
| Part Number | 9474LE |
| 3M ID | 7100083703 |
| UPC Code | 50021200599182 |
| Adhesive Type | Acrylic (300LSE High Strength) |
| Overall Length | 36 inches |
| Overall Width | 24 inches (609.6 mm) |
| Total Tape Thickness without Liner | 6.7 mil (0.17 mm) |
| Carrier Material | Polyester Film |
| Primary Liner | 58# Polycoated Kraft Paper |
| Primary Liner Color | Tan |
| Primary Liner Thickness | 4.2 mil (0.11 mm) |
| Secondary Liner Color | Tan |
| Secondary Liner Thickness | 4.2 mil (0.11 mm) |
| Tape Color | Clear |
| Smallest Saleable Unit | Case |
| Quantity per Case | 100 Sheets |
| Temperature Range | -40°F to 300°F (-40°C to 149°C) |
| Chemical Resistance | Excellent to chemicals and solvents |
| Surface Energy Compatibility | Low Surface Energy (LSE) Plastics, Foam, Powder-Coated Surfaces |
| Liner Configuration | Dual Liner |
| Application Method | Hand applied or with dispenser |
| Brand | 3M™ |
| Product Category | Double Coated Tape / Adhesive Transfer Tape |
| Industry Classification | Industrial/Occupational Use Only |
Order 3M Double Coated Tape 9474LE Clear 24x36 Inch at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
