Premium 3M double-coated paper tape with strong rubber adhesive, 1/4 inch width, 36 yard length per roll. Ideal for splicing, mounting, and temporary holding applications. Withstands temperatures up to 150°F long-term. 144 rolls per case.
3M™ Double Coated Paper Tape 410M is a premium quick-grab double-coated tape engineered with a strong rubber adhesive that delivers dependable hold for temporary attachments and project stabilization across diverse industrial applications. This versatile tape adheres reliably to a wide variety of substrates including papers, foils, films, and fabrics, making it ideal for splicing, core starting, golf club grip attachment, and mounting applications. The tape features 3M™ Adhesive 860, a soft rubber resin pressure-sensitive adhesive system that provides high initial adhesion and excellent holding power while remaining hand-tearable for convenient application.
The construction incorporates a robust 54 lb. densified kraft paper release liner with distinctive green and white plaid pattern for easy identification and enhanced dimensional stability during die-cutting and automated dispensing processes. This premium paper carrier design increases overall strength while facilitating easy removability, making it suitable for construction, fabrication, arts and crafts applications. The tape withstands elevated temperature environments, tolerating long-term use at temperatures up to 150°F (66°C) with short-term capability reaching 180°F (82°C), ensuring reliable performance in demanding industrial settings.
Manufactured using a solvent-free process, 3M™ Double Coated Paper Tape 410M meets environmental best practices and sustainability goals while maintaining exceptional performance standards. This industrial-grade tape is specifically designed for professional use in sporting goods assembly and repair, printing plate mounting, and various manufacturing processes. Each case contains 144 rolls, providing comprehensive coverage for high-volume applications in fabrication shops, construction sites, and manufacturing facilities worldwide.
Key Features
- Quick-grab double-coated construction with strong rubber adhesive for instant bonding
- Dependable hold with reliable performance for temporary attachments and project stabilization
- Multipurpose applications including splicing, core starting, golf grip attachment, and printing plate mounting
- Temperature resistant from -40°F to 150°F long-term, with short-term capability to 180°F
- Hand-tearable paper tape with green and white plaid release liner for easy identification
- Solvent-free manufacturing process supporting environmental sustainability goals
- Suitable for construction, fabrication, arts, crafts, and sporting goods assembly
- Robust 54 lb. densified kraft paper carrier for enhanced strength and removability
- Excellent dimensional stability during die-cutting and automated dispensing processes
- Industrial-grade quality for professional workplace use in manufacturing and fabrication
Technical Specifications
| Specification |
Value |
| Product Name | 3M™ Double Coated Paper Tape 410M |
| Part Number | 410M |
| 3M Product Number | 410M |
| 3M ID | 7010300419 |
| UPC Code | 00051111188040 |
| Overall Width (Imperial) | 0.25 inch |
| Overall Width (Metric) | 6.35 mm |
| Overall Length (Imperial) | 36 yards |
| Overall Length (Metric) | 32.91 meters |
| Total Tape Thickness without Liner (Imperial) | 6 mil |
| Total Tape Thickness without Liner (Metric) | 0.15 mm |
| Face Side Adhesive Thickness (Imperial) | 3 mil |
| Face Side Adhesive Thickness (Metric) | 0.08 mm |
| Back Side Adhesive Thickness (Imperial) | 2 mil |
| Back Side Adhesive Thickness (Metric) | 0.05 mm |
| Primary Liner Thickness (Imperial) | 3 mil |
| Primary Liner Thickness (Metric) | 0.08 mm |
| Adhesive Type | Natural Rubber |
| Adhesive System | 3M™ Adhesive 860 - Soft Rubber Resin Pressure Sensitive |
| Backing Material | Paper |
| Primary Liner Color | Green Plaid |
| Product Color | Natural |
| Liner Material | 54 lb. Densified Kraft Paper |
| Minimum Operating Temperature (Fahrenheit) | -40°F |
| Minimum Operating Temperature (Celsius) | -40°C |
| Maximum Operating Temperature (Fahrenheit) | 200°F |
| Maximum Operating Temperature (Celsius) | 93°C |
| Long-Term Temperature Rating (Fahrenheit) | 150°F (66°C) |
| Short-Term Temperature Rating (Fahrenheit) | 180°F (82°C) |
| Indoor/Outdoor | Indoor/Outdoor |
| Application Type | Double Coated Tape |
| Industries | General Industrial |
| Smallest Saleable Unit | Roll |
| Units per Case | 144 Rolls |
| Brand | 3M™ |
| Manufacturing Process | Solvent-Free |
| Application Methods | Hand Application or Automatic Dispenser |
| Recommended Uses | Splicing, Core Starting, Golf Club Grips, Printing Plate Mounting, Temporary Holding |
| Use Category | Industrial/Occupational Use Only |
Order 3M Double Coated Paper Tape 410M Natural 1/4 inch at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
