Industrial-grade double-coated paper tape with strong rubber adhesive for splicing, temporary holding, and project stabilization. Features 9 mil thickness, temperature resistance up to 180°F, and hand-tearable design for easy application.
3M™ Double Coated Paper Tape 401M is a robust double-coated tape engineered with a strong rubber adhesive that offers dependable holding power for temporary attachments and project stabilization. Featuring a total thickness of 9 mils without the liner, this industrial-grade tape is specifically designed for splicing and core starting of papers, foils, films, and fabrics. The tape withstands elevated temperature environments, tolerating long-term use at temperatures up to 150°F (66°C) with short-term use capability up to 180°F (82°C). The adhesive is coated on a paper carrier designed to increase strength and facilitate removability, making it ideal for construction, fabrication, arts and crafts applications, and numerous other industrial uses.
This hand-tearable double coated paper tape features 3M™ Adhesive 860, a soft rubber resin pressure-sensitive adhesive system that provides high initial adhesion and excellent holding power to a wide variety of materials. The tape is mounted on a robust 54 lb. densified kraft paper release liner that is green and white plaid for easy identification. This premium construction adds dimensional stability to the tape during processes such as die-cutting and automated dispensing, while also allowing for easy deployment, reducing edge roll, and protecting the tape from humidity extremes. Additionally, 3M™ Double Coated Paper Tape 401M serves as a reliable solution for mounting rubber or photopolymer printing plates to print cylinders and attaching golf club grips.
Manufactured using a solvent-free process, this tape helps meet environmental best practices and sustainability goals while maintaining superior performance standards. The product comes in a convenient 72 roll per case format, with each roll measuring 1/2 inch width by 36 yards in length, making it an economical choice for high-volume industrial and occupational applications. The 3M™ Adhesive 860 system provides performance across a wide temperature range from -40°F/-40°C up to 150°F/65°C, with short-term heat resistance up to 200°F/93°C, ensuring reliability in diverse working environments.
Key Features
- Strong rubber adhesive provides instant bond on variety of substrates
- Double-coated thick construction offers reliable hold and project stabilization
- Hand-tearable design for easy application without tools or dispensers
- Temperature resistant from -40°F to 180°F for extreme environment use
- Solvent-free manufacturing process supports environmental sustainability goals
- Green and white plaid kraft paper liner for easy identification
- Ideal for splicing, core starting, printing plates, and golf club grips
- Reduces edge roll and protects from humidity extremes
- Suitable for construction, fabrication, arts and crafts applications
- Economical bulk packaging of 72 rolls per case
Technical Specifications
| Specification |
Value |
| Product Name | 3M™ Double Coated Paper Tape 401M |
| Part Number | 401M |
| UPC Code | 00051111917176 |
| Overall Width (Imperial) | 0.5 in |
| Overall Width (Metric) | 12.7 mm |
| Overall Length (Imperial) | 36 yd |
| Overall Length (Metric) | 32.91 m |
| Total Tape Thickness without Liner (Imperial) | 9 mil |
| Total Tape Thickness without Liner (Metric) | 0.228 mm |
| Backing Material | Paper |
| Carrier Material | Paper |
| Adhesive Type | Natural Rubber - 3M™ Adhesive 860 |
| Back Side Adhesive Thickness (Imperial) | 3 mil |
| Back Side Adhesive Thickness (Metric) | 0.08 mm |
| Face Side Adhesive Thickness (Imperial) | 3 mil |
| Face Side Adhesive Thickness (Metric) | 0.08 mm |
| Primary Liner Color | White/Green Plaid |
| Primary Liner Thickness (Imperial) | 3 mil |
| Primary Liner Thickness (Metric) | 0.08 mm |
| Product Color | Natural |
| Product Form | Roll |
| Smallest Saleable Unit | Roll |
| Units per Case | 72 Rolls |
| Master Size Length (Imperial) | 108 Linear Yard |
| Master Size Length (Metric) | 98.8 m |
| Master Size Width (Imperial) | 22 in |
| Master Size Width (Metric) | 56 cm |
| Minimum Operating Temperature (Fahrenheit) | -40°F |
| Minimum Operating Temperature (Celsius) | -40°C |
| Maximum Operating Temperature (Fahrenheit) | 180°F (short-term) |
| Maximum Operating Temperature (Celsius) | 82°C (short-term) |
| Long-term Operating Temperature (Fahrenheit) | 150°F |
| Long-term Operating Temperature (Celsius) | 66°C |
| Short-term Heat Resistance (Fahrenheit) | 200°F |
| Short-term Heat Resistance (Celsius) | 93°C |
| Brand | 3M™ |
| Industry | General Industrial |
| Manufacturing Process | Solvent-free |
| Liner Type | Densified Kraft Paper - 54 lb |
Order 3M Double Coated Paper Tape 401M Natural 1/2 inch at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
