Professional-grade double-coated paper tape with strong rubber adhesive for splicing, core starting, and temporary attachments. Withstands temperatures up to 150°F long-term and 180°F short-term. 36 rolls per case.
3M™ Double Coated Paper Tape 401M is a robust double-coated tape engineered with a strong rubber adhesive that offers dependable hold for temporary attachments and project stabilization. This professional-grade tape features a total thickness of 9 mils without the liner and is specifically designed for splicing and core starting of papers, foils, films, and fabrics. The tape demonstrates exceptional performance in elevated temperature environments, withstanding long-term use at temperatures up to 150°F (66°C) with short-term use capability up to 180°F (82°C).
The adhesive is coated on a premium paper carrier that increases strength and facilitates removability for diverse applications including construction, fabrication, arts and crafts, and industrial manufacturing. Additionally, 3M™ Double Coated Paper Tape 401M serves as a reliable solution for mounting rubber or photopolymer printing plates to print cylinders and attaching golf club grips. The tape is hand-tearable and features 3M™ Adhesive 860, a soft rubber resin pressure-sensitive adhesive system mounted on a robust 54 lb. densified kraft paper release liner with green and white plaid identification pattern.
Manufactured using a solvent-free process, this tape helps meet environmental best practices and sustainability goals. The paper release liner adds dimensional stability during die-cutting and automated dispensing processes, allows for easy deployment, reduces edge roll, and protects the tape from humidity extremes. Each case contains 36 rolls, making it ideal for high-volume industrial applications and professional use across multiple industries.
Key Features
- Quick Grab Technology - Strong adhesive provides instant bond on variety of substrates
- Double-Coated Construction - Thick robust design offers reliable hold and project stabilization
- Temperature Resistant - Long-term use up to 150°F (66°C), short-term up to 180°F (82°C)
- Multipurpose Applications - Ideal for splicing papers, foils, films, fabrics, golf grip attachment
- Hand-Tearable Design - Easy manual application without requiring specialized tools or dispensers
- Solvent-Free Manufacturing - Environmentally friendly production process meets sustainability goals
- Green and White Plaid Liner - Easy identification with 54 lb. densified kraft paper backing
- Industrial Grade - Suitable for construction, fabrication, arts and crafts, and manufacturing
Technical Specifications
| Specification |
Value |
| Product Number | 401M |
| UPC Code | 00051115320552 |
| 3M ID | 7000144721 |
| Overall Width (Imperial) | 1 inch |
| Overall Width (Metric) | 25.4 mm |
| Overall Length (Imperial) | 36 yards |
| Overall Length (Metric) | 32.91 meters |
| Overall Thickness (Imperial) | 9 mil |
| Total Tape Thickness without Liner (Imperial) | 9 mil |
| Total Tape Thickness without Liner (Metric) | 0.228 mm |
| Backing Material | Paper |
| Carrier Material | Paper |
| Product Color | Natural |
| Adhesive Type | Natural Rubber |
| Adhesive System | 3M™ Adhesive 860 - Soft Rubber Resin Pressure Sensitive |
| Number of Adhesive Sides | Double-sided |
| Front Side Adhesive Thickness (Imperial) | 3 mil |
| Front Side Adhesive Thickness (Metric) | 0.08 mm |
| Back Side Adhesive Thickness (Imperial) | 3 mil |
| Back Side Adhesive Thickness (Metric) | 0.08 mm |
| Primary Liner Color | White/Green Plaid |
| Primary Liner Thickness (Imperial) | 3 mil |
| Primary Liner Thickness (Metric) | 0.08 mm |
| Liner Material | 54 lb. Densified Kraft Paper |
| Maximum Operating Temperature (Fahrenheit) | 180°F (short-term), 150°F (long-term) |
| Maximum Operating Temperature (Celsius) | 82°C (short-term), 66°C (long-term) |
| Minimum Operating Temperature (Fahrenheit) | -40°F |
| Minimum Operating Temperature (Celsius) | -40°C |
| Product Form | Roll |
| Units per Case | 36 rolls |
| Smallest Saleable Unit | Roll |
| Master Size Length (Imperial) | 108 linear yards |
| Master Size Length (Metric) | 98.8 meters |
| Master Size Width (Imperial) | 22 inches |
| Master Size Width (Metric) | 56 centimeters |
| Brand | 3M™ |
| Industry Classification | General Industrial |
| Manufacturing Process | Solvent-free |
| Application Type | Temporary Holding, Bonding, Attaching |
Order 3M Double Coated Paper Tape 401M Natural 1 inch 36 yard at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
