Shop 3M Cushion-Mount Plus Plate Mounting Tape E1320H Yellow In Iraq Best Prices

Premium 20 mil yellow foam plate mounting tape with air release technology for flexographic printing. Features differential acrylate adhesive, bubble-free mounting, and clean removal for high-quality combination printing on cylinders and sleeves.

The 3M™ Cushion-Mount™ Plus Plate Mounting Tape E1320H is a premium yellow foam tape specifically engineered for flexographic plate mounting applications. This 20 mil double-coated foam tape features advanced air release technology with plate side adhesive technology designed to resist edge lifting on flexographic print plates. The medium soft density foam is ideal for printing combinations of solids and process with halftone dots, making it perfect for high-quality combination printing on flexographic presses. This professional-grade mounting tape securely bonds flexographic photopolymer plates to print sleeves or steel cylinders while preventing plate edge lifting during printing operations. The E1320H variant offers higher plate side adhesion for challenging print conditions that use thick plates or small print sleeves. The innovative cross-hatch pattern from the release liner creates unique micro-channels in the adhesive that allow entrapped air to escape, ensuring virtually bubble-free mounting. Print plates mounted on E1320H will have no air bubbles under the plate due to this air release feature, resulting in cleaner print quality and higher productivity. The tape features differential acrylate adhesive system on each side of the foam carrier, with the linered (plate) side adhesive designed for mounting photopolymer plates and the non-linered (sleeve/cylinder) side designed for easy application and clean removal. With a 24-month shelf life and 2-year warranty from date of manufacture, this tape is manufactured to extremely tight caliper tolerances, allowing printers to use tape from different manufacturing lots while maintaining tight print registration. The compressible polyethylene foam backing withstands long and high-speed print runs, making it an essential product for professional flexographic printing operations.

Key Features

0.020 inch (0.51 mm) double coated foam tape with air release feature
Plate side adhesive technology designed to resist edge lifting on flexographic print plates
Medium soft density foam ideal for printing combinations of solids and process with halftone dots
Virtually bubble-free mounting with cross-hatch pattern micro-channels for air escape
Higher plate side adhesion for challenging print conditions with thick plates or small print sleeves
Clean plate removal without adhesive residue and tape removal from sleeve or cylinder
Tight caliper tolerance for consistent print registration across multiple manufacturing lots
Compressible polyethylene foam backing withstands long and high-speed print runs
24-month shelf life and 2-year warranty from date of manufacture
Engineered acrylic adhesives for reliable performance in professional printing operations

Technical Specifications

Specification	Value
Product Number	E1320H
3M ID	7100314604
UPC	00068060006073
Application Thickness (Imperial)	20 mil
Application Thickness (Metric)	0.5 mm
Overall Width (Imperial)	27 in
Overall Width (Metric)	685.8 mm
Overall Length (Imperial)	36 yd
Overall Length (Metric)	32.918 m
Product Color	Yellow
Adhesive Type	Differential Acrylate
Backing Material	Polyethylene Foam
Primary Liner	Polycoated Polyester
Primary Liner Thickness (Imperial)	4.5 mil
Primary Liner Thickness (Metric)	0.11 mm
Print Quality	Combination Printing - Medium Soft
Print Quality Series	13 Series
Application	Flexographic Plate Mounting
Brand	Cushion-Mount™
Clean Removal	Yes
Industries	Print
Urethane Sleeves Compatible	Yes
Shelf Life	24 Months
Warranty Period	2 Years from Date of Manufacture
Manufactured Target Thickness (Imperial)	0.022 in
Manufactured Target Thickness (Metric)	0.56 mm
Plate Compatibility	Photopolymer Plates
Cylinder/Sleeve Compatibility	Stainless Steel Cylinder, Sleeve
Packaging	1 Roll/Case

Order 3M Cushion-Mount Plus Plate Mounting Tape E1320H Yellow at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
