Description

Shop 3M Cushion-Mount Plus Plate Mounting Tape E1315 Yellow In Iraq Best Prices

Professional 15 mil yellow foam plate mounting tape for flexographic printing with air release technology, bubble-free mounting, and superior edge lift resistance. 18 in x 36 yd roll.

The 3M™ Cushion-Mount™ Plus Plate Mounting Tape E1315 is a professional-grade yellow foam mounting tape specifically engineered for flexographic printing applications. This double-coated foam tape features an innovative air release technology with plate-side adhesive designed to resist edge lifting on flexographic print plates. The tape measures 18 inches wide by 36 yards long with a 15 mil thickness, making it ideal for mounting photopolymer plates to flexographic printing cylinders and sleeves. This medium soft density foam tape is optimized for printing combinations of solids and process with halftone dots, delivering superior print quality and consistency. The differential acrylate adhesive system on each side of the foam carrier is protected by a specially designed polycoated polyester release liner. The unique crosshatched pattern on the release liner imprints micro-channels into the easy mount adhesive, allowing entrapped air to escape and ensuring virtually bubble-free mounting. This innovative air release feature significantly reduces setup time and delivers smoother surfaces for cleaner print quality and higher productivity. The E1315 mounting tape provides excellent resistance to lifting during press operation, allowing for clean plate removal without adhesive residue. The tape also removes cleanly from the sleeve or steel print cylinder, making demounting hassle-free. With a 24-month shelf life and 2-year warranty from date of manufacture, this industrial-grade tape is manufactured to very tight caliper tolerance, allowing printers to use tape from different manufacturing lots while maintaining tight print registration. The compressible foam withstands long and high-speed print runs, making it an essential product for professional printing operations.

Key Features

0.015 inch (0.38 mm) double coated foam tape with air release feature for bubble-free mounting
Medium soft density foam ideal for printing combinations of solids and process with halftone dots
Plate-side adhesive technology designed to resist edge lifting on flexographic print plates
Crosshatched release liner pattern imprints micro-channels for easy air escape and reduced setup time
Higher plate side adhesion for challenging print conditions with thick plates or small print sleeves
Clean plate demounting without adhesive residue and clean removal from sleeve or steel cylinder
Differential acrylate adhesive system on both sides of foam carrier
Tight caliper tolerance allows use of tape from different manufacturing lots
Compressible foam withstands long and high-speed print runs
Yellow foam color indicates medium soft density for combination printing

Technical Specifications

Specification	Value
Product Model	3M Cushion-Mount Plus Plate Mounting Tape E1315
Product Number	E1315
3M ID	7100312112
UPC	00068060005144
Overall Width (Imperial)	18 in
Overall Width (Metric)	457.2 mm
Overall Length (Imperial)	36 yd
Overall Length (Metric)	32.918 m
Application Thickness (Imperial)	15 mil
Application Thickness (Metric)	0.381 mm
Product Color	Yellow
Adhesive Type	Differential Acrylate
Backing Material	Polyethylene Foam
Primary Liner	Polycoated Polyester
Primary Liner Thickness (Imperial)	4.5 mil
Primary Liner Thickness (Metric)	0.11 mm
Print Quality	Combination Printing - Medium Soft
Print Quality Series	13 Series
Clean Removal	Yes
Shelf Life	24 Months
Warranty Period	2 Years from Date of Manufacture
Urethane Sleeves Compatible	Yes
Industries	Print
Brand	Cushion-Mount
Packaging	1 Roll/Case

Order 3M Cushion-Mount Plus Plate Mounting Tape E1315 Yellow at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
