Description

Shop 3M Cushion-Mount Plus Plate Mounting Tape E1020 White 36x36 In Iraq Best Prices

Premium flexographic plate mounting tape with air release technology, bubble-free application, and clean demounting for professional printing operations

The 3M Cushion-Mount Plus Plate Mounting Tape E1020 is a premium double-coated foam tape specifically engineered for flexographic printing applications. This white foam mounting tape features a 0.020 inch (0.51 mm) thickness with differential acrylate adhesive on both sides, protected by a polycoated polyester release liner. The tape is designed to securely bond flexographic photopolymer plates to print sleeves or steel cylinders while preventing plate edge lifting during high-speed printing operations. This specialized tape incorporates advanced air release technology with a unique crosshatched pattern in the release liner that creates micro-channels in the easy-mount adhesive. These micro-channels allow entrapped air to escape during application, ensuring virtually bubble-free mounting for superior print quality. The standard medium density polyethylene foam backing provides ideal cushioning for printing combinations of solids, process colors, and halftone dots, making it the industry standard for combination printing applications. The E1020 tape delivers exceptional performance with easy plate mounting and clean demounting without adhesive residue. The plate-side adhesive is specifically formulated for photopolymer plate mounting, while the sleeve/cylinder-side adhesive ensures secure application and clean removal. With a 2-year warranty from date of manufacture and engineered for tight caliper tolerance, this tape maintains consistent print registration across multiple manufacturing lots and supports long, high-speed print runs in wide-web press environments.

Key Features

Double-coated foam tape with differential acrylate adhesive for secure plate mounting
Advanced air release technology with crosshatched pattern for bubble-free application
Standard medium density polyethylene foam ideal for combination, process, and halftone printing
Easy mount and clean demount without adhesive residue on plates or print cylinders
Engineered for tight caliper tolerance with consistent performance across manufacturing lots

Technical Specifications

Specification	Value
Product Number	E1020
3M ID	7100311486
UPC Code	00068060004895
Overall Width (Imperial)	36 in
Overall Width (Metric)	914.4 mm
Overall Length (Imperial)	36 yd
Overall Length (Metric)	32.918 m
Application Thickness (Imperial)	20 mil
Application Thickness (Metric)	0.508 mm
Product Color	White
Adhesive Type	Differential Acrylate
Backing Material	Polyethylene Foam
Primary Liner	Polycoated Polyester
Primary Liner Thickness (Imperial)	4.5 mil
Primary Liner Thickness (Metric)	0.11 mm
Print Quality	Combination Printing - Standard
Print Quality Series	10 Series
Brand	Cushion-Mount Plus
Industry Application	Print - Flexographic
Urethane Sleeves Compatible	Yes
Warranty Period	2 Years from Date of Manufacture
Packaging	1 Roll per Case
Recommended Application	Flexographic plate mounting to printing cylinders and sleeves

Order 3M Cushion-Mount Plus Plate Mounting Tape E1020 White 36x36 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
