Premium 3/4 inch adhesive transfer tape with extended liner for easy application and superior bonding across multiple substrates including paper, plastic, foam and metal. Industrial-grade acrylic adhesive with 1000 yard length per roll.
3M™ Adhesive Transfer Tape Extended Liner 920XL is a premium general-purpose pressure-sensitive adhesive tape designed for industrial bonding applications. This translucent tape features an extended paper liner that extends beyond the width of the adhesive, providing exceptional ease of liner starting and removal. The tape is constructed with acrylic adhesive that delivers high initial adhesion and excellent shear holding power, making it ideal for bonding paper materials and a variety of different substrates including coated and uncoated papers, films, plastics, foams, and metals.
The 920XL tape comes with convenient dry edge and finger lift edge liners on each side for added user convenience and reduced equipment maintenance. With a total thickness of 1 mil without the liner and dimensions of 3/4 inch width by 1000 yards length, this tape is packaged in cases of 9 rolls for industrial and occupational use. The extended liner design is thinner than the 450XL variant, offering improved performance characteristics for demanding applications.
This adhesive transfer tape is engineered specifically for applications including cardboard shipping boxes, overnight mailer envelopes, pharmaceutical outserts, point of purchase displays, core starting, business forms, and various paper-to-paper bonding applications. Operating effectively across a temperature range from -40°F to 180°F, the 920XL maintains consistent performance in diverse industrial environments. The primary liner is constructed from 42.5# densified kraft paper with white coloring and 2.5 mil thickness, ensuring reliable protection and easy handling throughout the application process.
Key Features
- Extended liner design that extends beyond adhesive width for easy starting and removal
- Dry edge and finger lift edge liners on both sides for user convenience
- Tack-free tape roll edges for ease of use and reduced equipment maintenance
- High initial adhesion with excellent shear holding power for reliable bonding
- Pressure-sensitive acrylic adhesive suitable for multiple substrate types
- Temperature resistant from -40°F to 180°F for diverse industrial environments
- Thinner liner design compared to 450XL variant for improved performance
- Ideal for paper-to-paper, cardboard, and multi-material bonding applications
Technical Specifications
| Specification |
Value |
| Product Name | 3M™ Adhesive Transfer Tape Extended Liner 920XL |
| Part Number | 920XL |
| 3M ID | 7000001155 |
| UPC Code | 00021200038907 |
| Adhesive Type | Acrylic |
| Overall Width (Imperial) | 3/4 inch (0.75 in) |
| Overall Width (Metric) | 25.4 mm |
| Overall Length (Imperial) | 1000 yards |
| Overall Length (Metric) | 914.4 meters |
| Total Tape Thickness without Liner (Imperial) | 1 mil |
| Total Tape Thickness without Liner (Metric) | 0.025 mm |
| Primary Liner Material | 42.5# Densified Kraft Paper |
| Primary Liner Color | White |
| Primary Liner Thickness (Imperial) | 2.5 mil |
| Primary Liner Thickness (Metric) | 0.06 mm |
| Minimum Operating Temperature (Fahrenheit) | -40°F |
| Maximum Operating Temperature (Fahrenheit) | 180°F |
| Smallest Saleable Unit | Roll |
| Units per Case | 9 Rolls |
| Tape Color | Translucent |
| Recommended Applications | Cardboard shipping boxes, overnight mailer envelopes, pharmaceutical outserts, point of purchase displays, core starting, business forms, paper-to-paper applications |
| Compatible Substrates | Coated and uncoated papers, films, plastics, foams, metals |
| Brand | 3M™ |
| Industries | General Industrial, Medical, Packaging, Paper, Print, Retail |
| Use Type | Industrial/Occupational Use Only |
Order 3M Adhesive Transfer Tape Extended Liner 920XL 3/4 inch at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
