High-performance double-sided adhesive transfer tape with 3M High Temperature Acrylic Adhesive 100, offering exceptional strength at temperatures up to 450°F with low outgassing for aerospace and electronics applications.
3M™ Adhesive Transfer Tape 9462P is a premium double-sided transparent adhesive transfer tape engineered for demanding high-temperature applications in aerospace, automotive, and electronics industries. This 2.3 mil thick tape features 3M's High Temperature Acrylic Adhesive 100, specifically formulated to maintain exceptional bond strength in extreme conditions. The tape leverages low outgassing properties that meet NASA low outgassing specifications (ASTM E 595), making it ideal for space-qualified applications where material purity is critical.
The 55# densified kraft paper release liner reduces edge burr during hand tool processing of metal plates, ensuring clean, professional results. This tape delivers outstanding UV and chemical resistance for long-lasting performance, with short-term temperature tolerance up to 450°F (232°C). The combination of high peel strength and exceptional shear strength creates tough, durable bonds suitable for the most demanding aerospace bonding applications, flexible printed circuit (FPC) attachments, and automotive LED assembly.
Designed exclusively for industrial and occupational use, 3M Adhesive Transfer Tape 9462P provides the reliability and resilience required for mission-critical applications. Its transparent formulation allows for visual inspection of bonded surfaces, while the acrylic adhesive system ensures compatibility with both high surface energy (HSE) and low surface energy (LSE) plastics, as well as metal substrates.
Key Features
- Low outgassing properties meeting NASA ASTM E 595 specifications for aerospace applications
- Double-sided transparent design with 2.3 mil thickness for high-strength bonding
- High Temperature Acrylic Adhesive 100 rated for short-term use up to 450°F (232°C)
- 55# densified kraft paper release liner reduces edge burr in metal plate processing
- Outstanding UV and chemical resistance for long-lasting performance
- High peel and shear strength suitable for extreme condition bonding
- Compatible with high surface energy (HSE) and low surface energy (LSE) plastics
- Ideal for flexible printed circuit (FPC) attachment and automotive LED assembly
Technical Specifications
| Specification |
Value |
| Product Number | 3M 9462P |
| Adhesive Type | High Temperature Acrylic Adhesive 100 |
| Total Tape Thickness without Liner | 2.3 mil (0.06 mm) |
| Number of Adhesive Sides | Double-sided |
| Primary Liner Material | 55# Densified Kraft Paper |
| Primary Liner Color | White |
| Primary Liner Thickness | 3.2 mil (0.08 mm) |
| Maximum Operating Temperature | 450°F (232°C) short-term |
| Minimum Operating Temperature | -40°F (-40°C) |
| Transparency | Clear/Transparent |
| Peel Strength Rating | 3 (High) |
| Shear Strength Rating | 9 (Excellent) |
| Chemical Resistance | Excellent (Rating 9) |
| UV Resistance | Excellent (Rating 10) |
| Humidity Resistance | Excellent (Rating 10) |
| Smallest Saleable Unit | Roll |
| Adhesion to Metal | Excellent (Rating 10) |
| Adhesion to HSE Plastic | Excellent (Rating 10) |
| Adhesion to LSE Plastic | Excellent (Rating 9) |
| NASA Outgassing Compliance | ASTM E 595 (TML ≤ 1.00%, CVCM ≤ 0.10%) |
Order 3M Adhesive Transfer Tape 9462P Clear High Temperature at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
