High-performance 5 mil adhesive transfer tape with 200MP acrylic adhesive for exceptional bonding on metals and HSE plastics, featuring 16 in x 60 yd roll with polycoated kraft paper liner.
3M™ Adhesive Transfer Tape 468MP is a premium industrial-grade bonding solution featuring High Performance Acrylic Adhesive 200MP that delivers exceptional peel and shear strength for metals and high surface energy plastics. This 5 mil thick tape comes on a 58# polycoated kraft paper liner and measures 16 inches wide by 60 yards long, making it ideal for high-speed processing applications including medical components, durable labels, and flexible circuits. The tape is temporarily repositionable for accurate placement and provides outstanding performance after exposure to humidity and temperature fluctuations.
The 468MP tape features a thicker 5.2 mil adhesive layer that improves wet-out capability and adhesion on textured surfaces, ensuring reliable bonding even on imperfect substrates. With excellent resistance to solvents, humidity, and moisture, this tape maintains its performance at temperatures up to 400°F (204°C) for short periods and operates reliably in temperatures as low as -40°F (-40°C). The 200MP acrylic adhesive is recognized as the industry standard for graphic attachment and general industrial joining applications, backed by over 30 years of proven performance.
Specifically designed for bonding metal nameplates, rating plates, and graphic overlays to textured metal and high surface energy plastics, this adhesive transfer tape is suitable for membrane switch assembly, appliance graphic overlays, and point-of-purchase displays. The polycoated kraft paper liner provides excellent support for rotary processing of graphic and die-cut parts, making it an efficient choice for high-volume manufacturing operations. This product is for industrial and occupational use only and meets UL 746C and UL 969 specifications.
Key Features
- Exceptional peel and shear strength for metals and high surface energy plastics
- 5.2 mil thick adhesive layer improves wet-out and adhesion on textured surfaces
- 58# polycoated kraft paper liner for high-strength bonding and rotary processing
- Temporarily repositionable for accurate placement before final bonding
- Excellent resistance to solvents, humidity, moisture and temperatures up to 400°F (204°C)
- Industry-standard 200MP acrylic adhesive with over 30 years proven performance
- Operates reliably from -40°F to 400°F (-40°C to 204°C)
- Ideal for high-speed processing of medical components, labels, and circuits
- Suitable for graphic overlays, membrane switches, and nameplate applications
- Meets UL 746C and UL 969 specifications
Technical Specifications
| Specification |
Value |
| Part Number | 468MP |
| 3M Product Number | 468MP |
| UPC | 00021200188824 |
| Overall Width (Imperial) | 16 in |
| Overall Width (Metric) | 406.4 mm |
| Overall Length (Imperial) | 60 yd |
| Overall Length (Metric) | 54.86 m |
| Total Tape Thickness without Liner (Imperial) | 5 mil |
| Total Tape Thickness without Liner (Metric) | 0.127 mm |
| Adhesive Thickness | 5.2 mil |
| Adhesive Type | High Performance Acrylic Adhesive 200MP |
| Primary Liner | 58# Polycoated Kraft Paper |
| Primary Liner Color | Tan |
| Primary Liner Thickness (Imperial) | 4.2 mil |
| Primary Liner Thickness (Metric) | 0.11 mm |
| Product Color | Transparent |
| Product Form | Roll |
| Number of Adhesive Sides | Double-sided |
| Smallest Saleable Unit | Roll |
| Units per Case | 1.0 Roll |
| Maximum Operating Temperature (Fahrenheit) | 400 ℉ |
| Maximum Operating Temperature (Celsius) | 204 ℃ |
| Minimum Operating Temperature (Fahrenheit) | -40 ℉ |
| Minimum Operating Temperature (Celsius) | -40 ℃ |
| Indoor/Outdoor | Indoor/Outdoor |
| Moisture Resistant | No |
| Flame Retardant | No |
| Shelf Life | 24 Month |
| Specifications Met | UL 746C, UL 969 |
| Automotive OEM Specification | GMW 14892, Ford WSS-M99P48-B3 |
| Application | Bonding, Commercial Signs, Emblem Attachment, Large Surface Lamination Assembly, Mounting & Trim Attachment |
| Industries | Appliance, Automotive, Consumer Goods, Converter Solutions, Electronics, Furniture, General Industrial, Point of Purchase, Signage, Specialty Vehicles, Transportation |
| Brand | 3M™ |
