Shop Snap-On 10 mm 12-Point Metric Flank Drive® Long Combination Wrench | OEXLM10B In Iraq Best Prices
Professional 10mm metric combination wrench with 12-point Flank Drive design, 186mm long handle for enhanced leverage, forged steel construction, and 7.5° offset for restricted clearance access
The Snap-on 10mm 12-Point Metric Flank Drive Long Combination Wrench (Model OEXLM10B) is a premium professional-grade hand tool engineered for demanding industrial applications. This wrench features a continuous arc design that distributes stress evenly across the entire wrench opening radius, delivering exceptional strength and reliability in high-torque situations. Forged from superior steel and heat-treated to precise hardness specifications, this tool provides the durability and wear resistance required in aviation, aerospace, military, defense, oil and gas, power generation, railroad, and general industrial maintenance environments.
The innovative 7.5° offset broaching design allows users to flip the box end over to achieve more advantageous grip positions on fasteners in restricted clearance areas, maximizing accessibility and control. With a length of 186mm, the long handle provides 10-20% more leverage than standard-length handles, reducing user fatigue and enabling superior fastening power. The 12-point design ensures compatibility with a wide range of fastener types while the chrome finish provides corrosion resistance and a professional appearance that maintains its luster through years of demanding use.
This metric wrench meets ASME B107.100 standards, guaranteeing compliance with international quality and safety specifications. Whether you're working in confined spaces or demanding industrial settings, this Flank Drive combination wrench delivers the precision, strength, and reliability that professional technicians and maintenance crews depend on.
Key Features
- Continuous arc design distributes stress over entire wrench opening radius for superior strength
- Forged steel with heat treat hardness for exceptional durability and reduced wear
- 7.5° offset broaching allows flexible grip positioning in restricted clearance areas
- Long handle provides 10-20% more leverage than standard-length wrenches
- 12-point design ensures compatibility with various fastener types
- Chrome finish provides corrosion resistance and professional appearance
- Meets ASME B107.100 international quality and safety standards
- Precision-engineered for professional industrial maintenance applications
Technical Specifications
| Specification |
Value |
| Model Number | OEXLM10B |
| Size | 10mm |
| Style | 12-Point |
| Type | Metric Flank Drive Combination Wrench |
| Handle Type | Long Handle |
| Total Length | 186mm |
| Dimension A (Outside Diameter) | 15mm |
| Dimension B (Outside Diameter) | 21mm |
| Dimension C (Head Depth) | 7mm |
| Dimension D (Head Depth) | 5mm |
| Finish | Chrome |
| Material | Forged Steel |
| Offset Design | 7.5° Offset Broaching |
| Standards Compliance | ASME B107.100 |
| Handle Length Advantage | 10-20% longer than standard handles |
Order Snap-On 10 mm 12-Point Metric Flank Drive® Long Combination Wrench | OEXLM10B at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
